120-277VAC / 347-480VAC

  IP66 Rated

  cULus Certified

The FLE Series is best suited for flood light applications. Utilizing high-performance LED’s and visually aesthetic construction, this fixture is a great solution for replacing any older style HID floods.

Use: Building Exteriors, Recreational Facilities, Commercial Stores, High Mounted Applications, General Lighting, Manufacturing, Yard Lighting

Options Available

Mounting: Slip Fitter - Pole Mount / Trunnion Mount / Standard Bracket
Cable Whip: 18 AWG SOOW (Trunnion Option Only) / Plug End / Twist Lock / Inline Fusing
Comparable to: 250W-1000W H.I.D
Certified for general locations.

Spec Sheet - FLE

IES Files - FLE

Installation Manual -FLE

Specifications - FLE LED Flood Light

Voltage 120-277VAC or 347-480VAC
Power Factor ≤ 95%
LED Luminous Efficiency 130 (Lm/W)
Colour Temperature 3000-5700K
Colour Rendering Index Ra ≥ 70
Maximum Intensity Angle 90° x 120°
Work Temperature -40°C to + 40°C
Work Humidity 15% to 95% RH
Chip Life Expectancy 80,000 Hours (LM-70)
Fixture Aluminum Alloy Housing
Lens Optical Poly-Carbonate
Weight 1.45-9.5 kg
Protection IP66
Approved  Tested To UL Standards


•Building exteriors
•Light Industrial
•General Lighting
•Area Lighting
•Task Lighting
•Yard Lighting
•Low/Medium/High Mounting Applications

Our Warranty

We have a standard full replacement 5-year warranty.
