SL660

  100W/120W/200W/400W

  120-277VAC / 347-480VAC

  IP65 Rated

  cULus Certified

The SL660 series Area Light is suited for various outdoor high mounted area lighting applications. This fixture is equipped with high-performance LED’s along with high quality construction offering industry leading performance and durability for your outdoor area lighting needs.

Use: Parking Lots, Building Exteriors, Recreational Facilities, Commercial Stores, High Mounted Applications,General Lighting, Manufacturing, Yard Lighting

Options Available

Mounting: Slip Fitter - Pole Mount / Post Mount / Trunnion Mount
Cable Whip: 18 AWG SOOW (Trunnion Option Only) / Plug End / Twist Lock / Inline Fusing
Comparable to: 200W-1000W H.I.D
Certified for general locations.

Spec Sheet - SL660

IES Files - SL660

Installation Manual - SL660

Specifications - SL660 LED Flood Light

Voltage 120-277VAC or 347-480VAC
Power Factor ≤ 95%
LED Luminous Efficiency 150 (Lm/W)
Colour Temperature 3000-5700K
Colour Rendering Index Ra ≥ 70
Maximum Intensity Angle TYPE III/IV/V
Work Temperature -40°C to + 50°C
Work Humidity 15% to 95% RH
Chip Life Expectancy 80,000 Hours (LM-70)
Fixture Aluminum Alloy Housing
Lens Optical Poly-Carbonate
Weight 7.46-17.8kg
Protection IP65
Approved  Tested To UL Standards

Applications

• Warehousing Buildings
• Sports Arenas
• Recreational Facilities
• Commercial Stores
• High Mounted Applications
• General Lighting
• Parking Lots
• Manufacturing
• Storage

Our Warranty

We have a standard full replacement 5-year warranty.
