FL225 SERIES

10W, 20W & 30W Industrial LED Floodlights – FL225 Series

Use: Pathways, Walkways, Billboards, Security, Entrances, Overhead Doors, Low Mounting, Wet & Dry Locations, High Vibrations and Mobile Equipment.
Comparable to: 30-100 Watt H.I.D. fixtures

Certified for General and hazardous locations.

shadow

 Industrial LED Floodlight - Lumisave

Specifications

MULTI Voltage 120-277V**
Power Factor ≤ 95%
LED Luminous Efficiency 100 (Lm/W)
Colour Temperature 5000K**
Colour Rendering Index Ra > 70
Maximum Intensity Angle ≥ 120 Degree
Work Temperature -40°C to + 40°C
Work Humidity 10% to 95% RH
Chip Life Expectancy 80,000 Hours (LM70)
Fixture Black Aluminum Alloy Housing
Lens Tempered Glass**
Weight 4.5kg
Protection IP65, Wet Location
Approved ISO 9001, ISO14001, RoHS, CE, cETLus
Tested to CSA and UL Standards
**Lumisave can produce additional specifications. Available upon request

Comes with 7 foot SOOW cable.

Key Features

The high-powered LED chip offers superior brightness, proven to eliminate safety concerns while providing exceptional light quality for highly productive environments. Customizable options such as lenses, mounting (brackets) and various voltages make our product fit each customer’s needs

Why It’s Great

Pathways, Walkways, Entrances, and Overhead Doors are typical situations you can find the FL225 Series excelling in. There is no shortage of places where this multifunctional light can shine. Low & High Mounting , Wet & Dry Locations, High security situations or accent lighting. It can tolerate much abuse before the first signs of wear and tear.

Our Warranty

We have a standard full replacement 5 year warranty that we are well known in the industry for.

Available Accessories

Mounting: Standard Bracket, Heavy Duty Bracket, End Cap & Bracket, Magnetic Mount
Lens: Tempered Glass, Frosted Diffuser, Lexan Diffuser
Cable Whip: 7′ SOOW cable, Plug End, Twist Lock, Inline Fusing

HD Bracket for Industrial LED Flood Lights - Lumisave

Standard Bracket

HD Bracket for Two Chip Industrial LED Flood Lights - Lumisave

HD Bracket

End Cap and Bracket for Industrial LED Flood Light mounting - Lumisave

End Cap and Bracket

Magnetic Mount for Industrial LED Flood Lights - Lumisave

Magnetic Mount
